Khoom Description
Element PU vaj huam sib luag rau chav freezer siv 42kg / m³ kaw-cell polyurethane ua npuas ncauj, npog nrog PPGI, stainless hlau, lossis aluminium alloy. Lub vaj huam sib luag cov pob qij txha muaj kev sib khi zoo heev, tiv thaiv huab cua txias thiab thermal bridging. Thickness ranges ntawm 50-200mm, haum rau kev cia txias, lub freezer, thiab moj tej tawg freezer compartments. Txhua qhov ntau thiab tsawg, RAL xim, thiab kev ntsuas hluav taws kub tuaj yeem hloov kho. Cov khoom yog lub teeb yuag, yooj yim rau nruab, txuag hluav taws xob, thiab ib puag ncig tus phooj ywg, siv dav hauv cov chaw tsim khoom noj, chaw muag tshuaj, chaw xa khoom txias, thiab kev ua zaub mov noj. Peb kuj muab cov khoom siv txias txias sib xws thiab cov khoom siv txias txias tsim kev daws teeb meem.
Khoom Description
|
Yam khoom |
Specification |
|
|
Chiller Room |
Qhov kub thiab txias: -5℃rau +5℃. |
70 hli lossis 100 hli vaj huam sib luag yog feem ntau xaiv, nyob ntawm chav tsev kub thiab huab cua. |
|
Lub Freezer Room |
Qhov kub thiab txias: -15 ℃ to -25 ℃ . |
150 mm vaj huam sib luag feem ntau xaiv rau ruaj khov qis- qhov kub thiab txias. |
|
Blast Lub Freezer |
Qhov kub thiab txias: -30 ℃ to -40 ℃ . |
200 hli vaj huam sib luag yog feem ntau xaiv rau siab rwb thaiv tsev thov thiab ceev khov daim ntaub ntawv. |
Factory Production
Cov khoom siv raw
Khoom siv: Sandwich vaj huam sib luag tsim nrog txheej txheej ntawm pre{0}}coated galvanized steel (0.4-0.8mm) los yog stainless hlau (SS304), thiab ib tug nruj polyurethane (PU) los yog PIR ua npuas ncauj core (50-250mm thickness).
Thermal rwb thaiv tsev: Tsawg thermal conductivity (0.024W / m·K) ua kom lub zog zoo dua.
Cam xauv System: Quick- txuas mechanism rau ceev, airtight sib dhos yam tsis muaj ntxiv sealing.
Durability: Corrosion-resistant hlau tig, ya raws-cov ntaub ntawv ua npuas ncauj, thiab lub neej ua haujlwm ntev (15+ xyoo).
Hluav taws kub tsis kam: PIR variant muab cov nplaim hluav taws zoo dua qub (txog B1 qhov ntsuas).
Kev kho kom haum: Muaj nyob rau hauv dav mus txog 1183mm, ntev mus txog 13.5m, nrog ntau yam deg tiav.
puf vaj huam sib luag txias khw chav Installation
Peb tsis tsuas yog muab siab -zoo customized PUF txias cia vaj huam sib luag, tab sis kuj muab ib qho ua tiav - nres txias cia txias. Peb muab kev pabcuam tag nrho -chain los ntawm thawj qhov chaw tshawb fawb thiab kev npaj kos duab, kev tsim qauv, kev xaiv parameter, kev hloov kho vaj huam sib luag, kev thauj mus los thiab kev xa khoom, ntawm -qhov chaw teeb tsa, commissioning, thiab tom qab- muag kev txhawb nqa, tshem tawm qhov xav tau rau cov neeg siv khoom los tswj ntau tus neeg nruab nrab thiab txuag sijhawm thiab siv zog.
Raws li tus neeg siv khoom qhov loj me, pawg khaws cia, lub hom phiaj kub, thiab pob nyiaj siv, pab pawg Element raug suav thiab pom zoo kom pom cov vaj huam sib luag tuab, qhov ntom ntom, thiab cov khoom siv teeb tsa kom haum rau qhov tshwj xeeb cia txias cia.
ib - nres kev daws teeb meem
pab neeg tshaj lij
siab zoo
Khoom Case
Kev lag luam zaub mov: Cia txias (0℃rau +10 degree), khov warehouses (-18℃rau -25 degree), thiab ultra-low temp freezers (-30℃rau -60℃).
Pharmaceuticals: Kev cia tshuaj tiv thaiv (2–8 degree), ntshav plasma khov (-30 degree), thiab chav kuaj ntsuas kub.
Kev siv tshuab: Tshuaj cia khoom, khoom siv hluav taws xob (chaw huv si), thiab khaws cia paj.
Khw muag khoom & Logistics: Supermarket chillers, tis hubs, thiab modular chav txias.
e
✔ Kev txhim kho sai dua- Cam xauv tsim txo lub sij hawm sib dhos los ntawm 40% vs.
✔ Kev txuag hluav taws xob- Txo cov thermal txuas, txiav cov nqi tub yees los ntawm 30%+.
✔ Muaj zog & Lub teeb yuag- Siab load-cov kabmob muaj peev xwm thaum tseem yooj yim los tuav.
✔ Hygienic & Tsawg-Kev tu- Smooth, tsis yog - ntxeem tau qhov chaw tiv thaiv pwm thiab ua kom yooj yim ntxuav.
✔ Txhim khu kev sealing- Tshem tawm cov pa xau rau kev tswj qhov kub thiab txias.
✔ Tus nqi -Cov- Tus nqi qis dua lub neej vim kev ua haujlwm ntev thiab kev siv hluav taws xob.
FAQ
Txhua Yam Koj Yuav Tsum Paub
'Nws yog qhov txaus los ua haujlwm nrog Element. amazingy koom, yooj yim rau kev sib txuas lus nrog. teb nrog iterations tom ntej, thiab ua haujlwm zoo nkauj.
Dab tsi thickness PU vaj huam sib luag kuv xav tau rau kuv chav txias?
75/100mm panels raug pom zoo rau 0 ~-5℃chiller chav; 150mm rau -18℃ntau chav freezer; 175/200mm rau -25℃~ -35℃blast freezers. Peb tuaj yeem muab cov lus qhia ua haujlwm thickness raws li koj qhov project kub.
Cov ntaub ntawv saum npoo thiab xim dab tsi muaj rau PU lub freezer panels?
Peb muab PPGI, 304/316 stainless hlau thiab embossed txhuas daim hlau. Cov xim txheem yog RAL9002, thiab lwm yam xim RAL tuaj yeem hloov kho raws li koj qhov kev thov.
Koj tuaj yeem kho qhov loj ntawm lub freezer chav panels?
Yog lawm. Standard zoo dav: 960/1000/1120mm, siab tshaj customizable ntev mus txog 11800mm. Hlau ntawv thickness ranges ntawm 0.4mm mus rau 0.7mm. Kev ntsuas hluav taws kub B1 / B2 yog xaiv tau.
Lub sij hawm xa khoom thiab kev them nqi ntawm Polyurethane Foam Insulation Sheets yog dab tsi?
Lub sij hawm xa tuaj ib txwm 15-20 hnub, thiab them nyiaj ua ntej TT 30%, tshuav nyiaj li cas TT 70% ua ntej xa khoom.
Nov yog cov laj thawj vim li cas peb lub vov tsev txias yog qhov kev xaiv zoo tshaj plaws rau koj qhov project:
✔ Tsawg thermal conductivity(0.022-0.025 W/m·K vs. PU's 0.023-0.028)
✔ Cov hluav taws kub ntau dua(B1/A-chav kawm vs. PU's B2 lossis EPS's flammable rating)
✔ Zoo dua noo noo tsis kam(kaw-cov qauv ntawm tes tiv thaiv kev nqus dej)
